FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
103 - NPN RF INTERNAL COMPONENTS 3
1 FB4-5501-000 1 PLATE, ADJUSTMENT
2 FB4-5518-000 1 DUCT, FAN
3 FH2-6532-000 1 CABLE, DRAWER J381
4 FB4-5517-000 1 SHEET, INSULATING
5 FH6-3858-000 1 SPEAKER J63
6 HB1-0611-000 1 MOUNT, SPEAKER
7 HB1-0612-000 1 HOLDER, SPEAKER
8 HB1-0772-000 1 DAMPAR, RUBBER
9 RS5-9056-000 2 SCREW,STEPPED,M3
10 VT2-0002-006 6 SPACER, SUPPORT
11 WT2-0301-000 2 CLIP, CABLE
12 WT2-0317-000 3 CLIP, CABLE
13 WT2-5026-000 1 CLIP, CABLE
14 WT2-5031-000 4 CLIP, CABLE
15 XA9-0629-000 3 SCREW,RS,M4X8
16 HH2-2482-000 1 POWER SUPPLY CORD 100V J190
RH2-5263-000 1 CORD, POWER SUPPLY 120V J190
RH2-5312-000 1 CORD, POWER SUPPLY 230V J190
17 FB1-6668-000 1 LEVER, SENSING
18 FB3-2791-000 1 ROLLER, SENSOR MOUNT
19 FB4-5528-000 1 COVER, SENSOR
20 FS2-2351-000 1 SPRING, TENSION
21 WG8-5362-000 1 IC, TLP1241, PHOTO-INTERRUPTER PS102 J67
22 XA9-0629-000 1 SCREW,RS,M4X8
23 XA9-0722-000 1 SCREW,RS,M4X12
24 FG2-9759-000 1 DC CABLE J61,62,66,67,91-94
J181-184
24 A VS1-5057-002 1 CONNECTOR, SNAP TIGHT J93
25 FB4-5562-000 1 CASE, PLAG
26 FH2-6524-000 1 AC CABLE J102,164
103-2
