Canon GP160DF - Page 689

FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
260 - FG6-1217-000 1 MAIN DRIVE ASSEMBLY
1 FB4-5704-000 1 PLATE, GEAR COVER
2 FB4-5705-000 1 LEVER, GEAR THRUST
3 FS7-0205-000 1 GEAR, 53T
4 RB2-1850-000 1 PIN
5 RB2-1852-000 1 SPRING, TORSION
6 RB2-1859-000 1 PLATE, DRUM
7 RF5-2409-000 1 ARM, SWING
8 RH7-1357-000 1 MOTOR, STEPPING, DC 24V M601 J601
9 RS5-1387-000 1 BUSHING
10 RS5-1388-000 1 BUSHING
11 RS5-2931-000 1 SPRING, COMPRESSION
12 RS6-0335-000 1 GEAR, 241T
13 RS6-0336-000 1 GEAR, 59T
14 RS6-0338-000 1 GEAR, 42T/24T
15 RS6-0342-000 1 GEAR, 31T/17T
16 RS6-0343-000 1 GEAR, 24T/21T
17 RS6-0344-000 1 GEAR, 18T
18 RS6-0345-000 1 GEAR, 36T/31T
19 RS6-0346-000 1 GEAR, 50T
20 RS6-0348-000 1 GEAR, 29T/14T
21 RS6-0337-000 1 GEAR, 36T/96T
22 XA9-0267-000 10 SCREW,TP,M3X6
260-2
