FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
300 - NPN RF CASSETTE
1 FB4-5814-000 1 PLATE, SIZE, REAR
2 FB4-5821-000 1 LABEL, SIZE INDEX
3 FF5-7269-000 1 PLATE, PAPER LIFTING
3A FB4-5817-000 2 PLATE, FRICTION
4 FS6-2918-000 2 SPRING, COMPRESION
5 FS7-0207-000 1 GEAR, 20T
6 FB4-5801-000 N 1 BODY, CASSETTE
7 FB4-5804-000 1 LEVER, PAPER SIZE
8 FF5-7274-000 1 LEVER
8A FB4-5825-000 1 LABEL
9 FB4-5806-000 1 BLOCK
10 FF5-7270-000 1 COVER, FRONT
10 A FB4-5803-000 1 SHEET, DISPLAY
11 FS6-2917-000 1 SPRING, TENSION
12 FB4-5807-000 1 PLATE, SIZE, FRONT
13 FB4-5808-000 1 PLATE, HOLD-DOWN TAB
14 FB4-5809-020 1 LEVER, LOCK
15 FB4-5810-000 1 PLATE, PAPER CONTACT
16 FB4-5811-000 1 SPRING, LEAF
17 FB4-5818-000 1 SPRING, LEAF
18 FF5-7273-000 1 PLATE, SIZE, REAR
18A FB4-5824-000 1 LABEL
19 FB4-5813-000 1 PLATE, HOLD-DOWN TAB
20 FB4-5820-000 1 LABEL, PAPER SIZE JAPANESE
FB4-5833-000 1 LABEL, PAPER SIZE OTHERS
21 FB4-5836-000 1 LABEL
22 FB4-5526-000 1 LABEL, SIZE
23 FB4-5815-000 1 PLATE, PAPER SIZE
501 XB4-7400-809 3 SCREW,TAPPING,TRUSS HEAD,M4X8
300-2
