FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
310 - FG6-1202-000 1 PAPER PICK-UP ASSEMBLY 100V
FG6-1278-000 1 PAPER PICK-UP ASSEMBLY 120/230V
1 FB4-5667-000 1 ROLLER, VERTICAL PATH
2 FB4-5668-000 1 ARM, PAPER
3 FB4-5669-000 2 ROLLER
4 RS1-1016-000 3 BUSHING
5 FB4-5696-000 1 SHAFT, CLUTCH
6 FB4-5698-000 1 SHAFT, RETARD
7 FB4-5699-000 1 SHAFT, MAIN
8 FS1-1205-000 1 BUSHING
9 FA9-2753-000 11 SCREW,M4X10
10 FS5-1854-000 1 BUSHING
11 FS6-2915-000 1 SPRING, TENSION
12 FS7-0194-000 1 GEAR, 19T
13 FS7-0195-000 1 GEAR, 58T/35T
14 FS7-0196-000 1 GEAR, 38T/62T
15 FS7-0197-000 1 GEAR, 24T
16 FS7-0198-000 1 GEAR, 19T
17 FS7-0200-000 1 GEAR, 39T/20T
18 FS7-0201-000 1 GEAR, 29T
19 RB1-2190-000 1 COLLAR, SPRING
20 RB1-6168-020 1 BUSHING
21 RB1-6179-000 1 BUSHING, RIGHT
22 RB1-8865-000 2 ROLLER
23 RB1-8945-000 1 JOINT
24 RH7-5174-000 1 SOLENOID SL301 J517
25 FB4-5654-000 1 GUIDE, PAPER
26 FB4-5655-000 1 SPRING, TORSION
27 FB4-5662-000 1 ARM, SENSOR
28 FB4-5665-000 1 HOLDER, SENSOR
310-2
