FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
325 - FG6-1239-000 1 REGISTRATION ROLLER ASSEMBLY 100V
FG6-1273-000 1 REGISTRATION ROLLER ASSEMBLY 120/230V
1 RS5-1386-000 1 BUSHING
2 RS5-1393-000 1 BUSHING
3 RB1-6168-020 1 BUSHING
4 RB1-6169-020 1 BUSHING
5 FS6-2942-000 2 SPRING, TENSION
6 RB2-1819-000 1 KNOB
7 RS6-0359-000 1 GEAR, 24T
8 RB2-1811-000 1 REGISTER ROLLER, LOWER
9 RB2-1812-000 1 SHAFT, REGISTER
10 RF5-2403-000 1 GUIDE, REGISTER, UPPER
10 A RB2-1843-000 1 SHEET
11 RF5-2404-000 1 GUIDE, REGISTER, LOWER 100V
FF5-7294-000 1 GUIDE, REGISTER, LOWER 120/230V
11 A RB2-1818-000 1 GUIDE, STOPPER
11 B RB2-1844-000 1 SHEET, 1 100V
FB4-5782-000 1 SHEET, 4 120/230V
11 C RB2-1845-000 1 SHEET, 2 100V
FB4-5783-000 1 SHEET, 5 120/230V
11 D RB2-1846-000 1 SHEET, 3
11E FB4-5780-000 2 BRUSH, STATIC CHARGE 120/230V
11F FB4-5781-000 1 BRUSH, STATIC CHARGE 120/230V
12 RB2-1837-000 2 ROLLER
13 RF5-1332-020 1 COVER, PAPER FEED
13 A RB1-6167-020 1 SHEET
14 RB2-1838-000 2 ROLLER
15 FB4-5766-000 1 ROLLER
16 RS5-1394-000 10 SPACER
17 RS6-0358-000 1 GEAR, 21T
325-2
