COPYRIGHT
©
1999 CANON INC. CANON GP160 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 3 EXPOSURE SYSTEM
3-7
7) Remove one of the inverter PCB’s [5]
connectors (CN2) [6].
8) Insert a screwdriver into the upper
frame metal sheet’s front and back
holes, and prise loose the 2 installa-
tion pins.
9) Removed a scanning lamp at slide.
Figure 3-303
Figure 3-304
