FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
810 - FG6-1219-060 1 FIXING ASSEMBLY 100V
1 RB2-1919-000 1 ROLLER, PRESSURE
2 RB2-1920-000 1 RUBBER
3 RB2-1924-000 1 GUIDE, PAPER
4 RB2-1930-000 2 PIN
5 FB4-5758-000 1 ROLLER, DELIVERY
6 RS5-1389-000 2 BUSHING
7 RS1-1087-000 1 BUSHING
8 RS5-1391-000 1 BUSHING
9 RS5-2950-000 2 SPRING, TENSION
10 RS5-2951-000 2 SPRING, COMPRESSION
11 RS6-0354-000 1 GEAR, 15T
12 RS6-0355-000 1 GEAR, 16/23T
13 RS6-0356-000 1 GEAR, 21T
14 XA9-0702-000 3 SCREW, M3
15 RB2-1940-000 1 LEVER, SENSOR
16 RB2-1943-000 1 SPRING, TORSION
17 FB4-5760-000 1 HOLDER, SENSOR
18 RG5-3540-000 1 THERMISTOR CABLE J1303,1304
19 RG5-3530-000 1 FIXING FILM ASSEMBLY J161,1302
20 RG5-3536-000 1 FIXING LEFT ASSEMBLY
21 RB2-1927-000 1 COVER, RIGHT
22 FB4-5603-000 1 PLATE, RELEASE
23 FB4-5759-030 1 GUIDE, DELIVERY
24 WG8-5362-000 1 IC, TLP1241, PHOTO-INTERRUPTER PS306 J1306
25 WT2-0495-000 1 CLAMP, CABLE
26 RB1-1447-000 6 ROLLER, DELIVERY, FIXING
27 RB2-1956-000 1 GUIDE, DELIVERY UPPER
28 RB2-1944-000 6 SPRING, LEAF
29 RG5-3541-000 1 FIXING DC CABLE J1305-1307
810-2
