FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.0 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
810A - FG6-1258-000 1 FIXING ASSEMBLY 120V
FG6-1259-000 1 FIXING ASSEMBLY 230V
1 RB2-1919-000 1 ROLLER, PRESSURE
2 RB2-1920-000 1 RUBBER
3 RB2-1924-000 1 GUIDE, PAPER
4 RB2-1930-000 2 PIN
5 FB4-5786-000 1 ROLLER, DELIVERY
6 RS5-1389-000 2 BUSHING
7 RS1-1087-000 1 BUSHING
8 RS5-1391-000 1 BUSHING
9 RS5-2950-000 2 SPRING, TENSION
10 RS5-2951-000 2 SPRING, COMPRESSION
11 FS7-0236-000 1 GEAR, 21T
12 FS7-0237-000 1 GEAR, 16T/17T
13 RS6-0356-000 1 GEAR, 21T
14 XA9-0702-000 5 SCREW, M3
15 FB4-5790-000 1 LEVER, SENSOR
16 FB4-5845-000 1 SPRING, TORSION
17 FB4-5795-000 1 PLATE, CROSSMEMBER
18 RG5-3540-000 1 THERMISTOR CABLE J1303,1304
19 RG5-3530-000 1 FIXING FILM ASSEMBLY 120V J161,1302
RG5-3531-000 1 FIXING FILM ASSEMBLY 230V J161,1302
20 FG6-1275-000 1 FIXING LEFT ASSEMBLY
21 RB2-1927-000 1 COVER, RIGHT
22 FB4-5800-000 4 SPRING, LEAF
23 FB4-5789-000 1 GUIDE, DELIVERY
24 WG8-5362-000 1 IC, TLP1241, PHOTO-INTERRUPTER PS306 J1306
25 WT2-0495-000 1 CLAMP, CABLE
26 XA9-0702-000 1 SCREW, M3
27 FB4-5647-000 1 ROLLER, HEATSINK
810A-2
