FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT
C
1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
930 - NPN RF DC CONTROLLER ASSEMBLY
1 FB4-5754-000 1 DC CONTAINER
2 FB4-5757-000 1 SHEET, INSULATING
3 FG2-9752-040 1 DC CONTROLLER PCB ASSEMBLY 100V
FG2-9769-000 1 DC CONTROLLER PCB ASSEMBLY 120V
FG2-9770-000 1 DC CONTROLLER PCB ASSEMBLY 230V
501 XB6-7300-607 6 SCREW,TP,M3X6
JH401 RB2-1902-000 1 PLATE, HIGH-VOLTAGE
JH402 RB2-1902-000 1 PLATE, HIGH-VOLTAGE
JH406 RB2-1902-000 1 PLATE, HIGH-VOLTAGE
JH407 RB2-1902-000 1 PLATE, HIGH-VOLTAGE
R465 RH6-3712-000 1 RESISTOR, 3MOHM, 0.48W
R489 RH6-3712-000 1 RESISTOR, 3MOHM, 0.48W
T401 RH3-5023-000 1 TRANSFORMER, INVERTER
T402 RH3-5024-000 1 TRANSFORMER, INVERTER
T403 RH3-5026-000 1 TRANSFORMER, INVERTER
T404 RH3-5025-000 1 TRANSFORMER, INVERTER
T405 RH3-5025-000 1 TRANSFORMER, INVERTER
T406 RH3-5027-000 1 TRANSFORMER, INVERTER
T407 RH3-5026-000 1 TRANSFORMER, INVERTER 120/230V
T408 RH3-5025-000 1 TRANSFORMER, INVERTER
TH302 RH7-7077-000 1 THERMISTOR
X30 1 RH5-0110-000 1 CRYSTAL OSCILLATOR
930-2
