FIGURE
&
KEY NO.
PART NUMBER DESCRIPTION SERIAL NUMBER / REMARKS
R
A
N
K
Q
/
T
Y
COPYRIGHT C 1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
P11 - NPN RF INTERNAL COMPONETS
1 FB4-5901-000 1 COVER, OPENING GRIP
2 FB4-5970-000 1 COVER, REAR
3 FF5-7301-000 1 CUSHION ASS'Y, COPYBOARD COVER
3A FB4-5903-000 1 COPYBOARD COVER
3B FB4-5958-000 1 COPYBOARD COVER
4 FH2-6558-000 1 CORD, GROUNDING
5 FH2-6557-000 1 DF CABLE J251,873,874
6 FH2-6563-000 1 SENSOR CABLE AB/A SIZE
J857,858,860
FH2-6564-000 1 SENSOR CABLE INCH/AB/A SIZE
J857-860
7 FS5-9545-000 3 SCREW, STEPPED, M4
8 FS5-9546-000 1 SCREW, M4X12
9 HB1-2016-000 1 COVER, COPYBOARD
10 HB1-2017-000 2 HOLDER, DLSP CABLE AB/A SIZE
HB1-2017-000 3 HOLDER, DLSP CABLE INCH/AB/A SIZE
11 WG8-5333-000 2 PHOTO-INTERRUPTER AB/A SIZE PS802,803
J857,858
WG8-5333-000 3 PHOTO-INTERRUPTER INCH/AB/A SIZE
PS802-804 J857-859
12 XA9-0591-000 AR SCREW,M3X8
13 XA9-0795-000 2 SCREW, TP, M4X12
14 XA9-0772-000 7 SCREW, P, M3X8
15 FG6-1306-000 1 HINGE, RIGHT
15A FH2-6562-000 1 SENSOR CABLE J863,864
15B WG8-5362-000 1 IC, TLP1241, PHOTO-INTERRUPTER PS806 J861
15C WT2-5547-000 1 CLIP, CABLE
15 D FB4-5948-000 1 ACTUATOR, SENSOR
15 E FB4-5949-000 1 HOLDER, SENSOR
15F FS6-2924-000 1 SPRING, COMPRETION
15 G FB4-5950-000 1 COVER, BASE
15H WT2-5056-000 1 CLIP, CABLE
15J WT2-0261-000 2 CLIP, CABLE
P11-2
