COPYRIGHT
C
1999 CANON INC. CANON 2220/2210/2200/160/3000 REV.1 FEB. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
GA-1
FIGURE GA
ASSEMBLY LOCATION DIAGRAM
G93
MODEM CONTROLLER PCB ASSEMBLY
G94
G94A
G93A
NCU BOARD PCB ASSEMBLY
G97
MODULAR PCB ASSEMBLY
