Canon imagePRESS 1135 User Manual

8
8
8-230
8-230
Service Mode > COPIER > OPTION (Mechanical specications Setting Mode) > FNC-SW
Service Mode > COPIER > OPTION (Mechanical specications Setting Mode) > FNC-SW
OPTION (Mechanical specications Setting Mode)
■
FNC-SW
COPIER > OPTION > FNC-SW
PO-CNT ON/OFF of potential control function
Lv.1 Details ON/OFF setting for potential control function.
Setting OFF formulates image without the potential sensor that can
help separating the trouble.
Use case To separate (identify) the cause of image fault to determine whether
it’s due to potential control.
Adj/set/operate method 1) Enter the setting value, and then press OK key.
2) Turn OFF and then ON the main power supply.
Caution Be sure to set the value back to 1 (ON) after servicing.
Display/adj/set range 0 to 1
0: OFF, 1: ON
Default value 1
MODEL-SZ Fixed mag ratio & DADF originl dtct size
Lv.1 Details Setting of the xed magnication ratio display and the original
detection size with DADF.
To be automatically specied at the time of installation according to
the location.
Use case Upon request from the user
Adj/set/operate method 1) Enter the setting value, and then press OK key.
2) Turn OFF and then ON the main power supply.
Display/adj/set range 0 to 3
0: AB conguration (6R5E) for Japan, 1: Inch conguration (5R4E)
for North/Middle/South America, 2: A conguration (3R3E) for
Europe, 3: AB/Inch conguration (6R5E) for Asia, Oceania, South
America
Default value The default differs according to the location.
SCANSLCT ON/OFF of scan area calculate function
Lv.2 Details ON/OFF setting of the function to calculate scanning area from the
specied paper size.
When the paper size is larger than the original size, selecting ON
reduces productivity because the scanning area gets larger.
Use case To match the scanning area with the paper size.
Adj/set/operate method 1) Enter the setting value, and then press OK key.
2) Turn OFF and then ON the main power supply.
Display/adj/set range 0 to 1
0: OFF (calculated from the detected original size)
1: ON (calculated from the specied paper size)
Default value 0
COPIER > OPTION > FNC-SW
SENS-CNF Setting of original detection size
Lv.2 Details Setting of original detection size according to AB conguration/Inch
conguration/A conguration.
Select 1 (Inch conguration) or 2 (A conguration) for Inch/
A-conguration machine.
Use case When replacing the reader controller PCB/at the time of RAM clear.
Adj/set/operate method 1) Enter the setting value, and then press OK key.
2) Turn OFF and then ON the main power supply.
Display/adj/set range 0 to 2
0 to 2. 0: AB conguration, 1: Inch conguration, 2: A conguration
Default value 0
CONFIG Country/area/langage/locatn/ppr size set
Lv.1 Details Setting of the country/region, language, location, paper size
conguration for multiple system software in HDD.
Use case Upon request from the user
Adj/set/operate method 1) Select the setting item.
2) Switch with +/- key, and then press OK key.
3) Turn OFF and then ON the main power supply.
Display/adj/set range XX YY.ZZ.AA
XX: Country/region
JP: Japan, US: United States, GB: England, FR: France,
DE: Germany, IT: Italia, AU: Australia, SG: Singapore,
NL: Netherlands, KR: Korea, CN: China, TW: Taiwan, ES: Spain,
SE: Sweden, PT: Portugal, NO: Norway, DK: Denmark, FI: Finland,
PL: Poland, HU: Hungary, CZ: Czech, SI: Slovenia, GR: Greek,
EE: Estonia, RU: Russia, AD: Andorra, AL: Albania, AM: Armenia,
AR: Argentine, AT: Austria, BA: Bosnia Herzegovina, BE: Belgium,
BG: Bulgaria, BO: Bolivia, BR: Brazil, CA: Canada, CH: Switzerland,
CL: Chile, CY: Cyprus, HR: Croatia, ID: Indonesia, IE: Ireland,
IL: Israel, IN: India, IS: Iseland, LU: Luxembourg, LV: Latvia,
MX: Mexico, MY: Malaysia, NZ: New Zealand, PE: Peru,
PH: Philippine, PY: Paraguay, RO: Romania, SK: Slovakia,
TH: Thailand, TR: Turkey, UA: Ukraine, UY: Uruguay, VE: Venezuela,
VN: Vietnam
YY: Language (xed, e.g. ja: Japanese)
ZZ: Location (xed, e.g. 00: CANON)
AA: Paper size conguration (00: AB conguration, 01: Inch
conguration, 02: A conguration, 03: Inch/AB conguration)
Related service mode COPIER> OPTION> FNC-SW> MODEL-SZ
