Installation > How to check this installation procedure > Symbols in the illustration
Installation > How to check this installation procedure > Symbols in the illustration
How to check this installation procedure
When using the contents (parts included in the
package)
After unpacking, check the parts included in the package by referring to the illustration of
“Contents” described in this procedure.
A symbol is described on the illustration in the case of using the parts included in the package
of this product.
Check the symbol to use the necessary parts from the contents in the package.
The symbol to indicate the parts to be used from the contents.
Symbols in the illustration
The frequently-performed operations/works are described with symbols in this procedure.
Check the description below.
To install / remove
Screw Connector Harness
Tighten Remove Connect Disconnect Connect/
Secure
Disconnect/
Free
Prohibition (Good/Bad) Checking instruction
Good Bad Check Visual check Sound
check
Instruction on direction (front/rear, top/bottom)
Push Connect to
the outlet
Turn ON the
switch
Copy
Remove the
projection
Fit in the
projection
Release/
remove the
claw
Fit in/attach
the claw
To Next Page
