Service Mode > SORTER > FUNCTION
Service Mode > SORTER > FUNCTION
SORTER> ADJUST
ST-ALG2 Adj Stacker LTR size align pstn: Fin-AG
Lv.1 Details To adjust the LTR size paper alignment position.
As the value is incremented by 1, the travel length of the Alignment
Plate is increased by 0.42 mm.
Use case When misalignment occurs in LTR size paper
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range -50 to 50
Unit 0.42 mm
Default value 0
PF-LGL41 Adj of LGL 4-fold position (1st): PFU
Lv.1 Details To adjust the 1st fold position of LGL paper 4-fold position on Paper
Folding Unit.
As the value is incremented by 1, the fold position moves by 0.5 mm.
Use case When the fold position adjustment in user mode is inadequate
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range -128 to 127
Unit 0.5 mm
Default value 0
PF-LGL42 Adj of LGL 4-fold position (2nd): PFU
Lv.1 Details To adjust the 2nd fold position of LGL paper 4-fold position on Paper
Folding Unit.
As the value is incremented by 1, the fold position moves by 0.5 mm.
Use case When the fold position adjustment in user mode is inadequate
Adj/set/operate method Enter the setting value, and then press OK key.
Display/adj/set range -128 to 127
Unit 0.5 mm
Default value 0
T-8-112
FUNCTION
SORTER> FUNCTION
PCH-STUP Auto adj of side registration: P-puncher
Lv.1 Details [Not used]
To automatically adjust the side registration position at the installation
of professional puncher.
Use case When adjusting the side registration position
Adj/set/operate method 1) Connect the machine with the puncher and turn ON the power.
2) Switch the hardware switch of the puncher to the setup mode side.
3) Sselect the item in service mode, and then press OK.
4) When "OK!" is displayed, set A4 or LTR original to any pickup
source and press a start key on the service mode screen display.
5) Copy operation is performed and the paper stops at the delivery
mouth of the puncher.
Caution Overseas machine only
CLEAR RAM clear of Fin-CON PCB: Fin-AF
Lv.1 Details To delete all the adjustment contents and counter information on the
îš¿nisher controller PCB.
Use case When the wrong setting is speciîš¿ed for the adjustment data
Adj/set/operate method Enter the setting value and press OK key.
FIN-BK-R Backup data read of CON PCB: Fin-AF
Lv.1 Details Backup data is read from the îš¿nisher controller PCB and saved on
the hard disk.
Use case At the replacement of îš¿nisher controller PCB
Adj/set/operate method Select the item and press OK key.
Display/adj/set range In processing: ACTIVE, at normal termination: OK, at abnormal
termination: NG
Required time Approx. 5 min
Related service mode SORTER> FUNCTION> FIN-BK-W
FLD-BK-W Backup data write of CON PCB: PFU
Lv.1 Details Backup data saved on the hard disk is written to the paper folding
unit controller PCB.
Use case At the replacement of paper folding unit controller PCB
Adj/set/operate method Select the item and press OK key.
Display/adj/set range In processing: ACTIVE, at normal termination: OK, at abnormal
termination: NG
Required time Approx. 5 min
Related service mode SORTER> FUNCTION> FLD-BK-R
