Installation > Installation > Fixing the top board
Installation > Installation > Fixing the top board
Fixing the top board
NOTE :
• When the color image reader is not installed simultaneously, x the top cover while
TONER-S is in progress.
• When installing the color image reader simultaneously, do not x the top cover.
1) Install the upper right cover 2, the upper cover and the upper left cover 2 on the rear side.
• 3 stepped screws (M4)
• 3 screws (TP; M4X8)
• 3 cover rubbers
NOTE :
• Cut the tap by the screw thread of stepped screw and tighten the screw.
• Once the stepped screw is installed, it won’t come off.
x6
F-9-100
2) Remove the upper front cover.
• 3 stepped screws (loosen)
F-9-101
3) Install the upper cover and the upper left cover 2 on the front side.
• 4 screws (TP; M4X8)
x4
F-9-102

Canon imagePRESS 1135 Specifications

General

Print Speed (Black)	135 ppm
Print Resolution	1200 x 1200 dpi
Maximum Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Operating System Compatibility	Windows, macOS, Linux
Print Technology	Laser
Maximum Paper Size	13 x 19.2 inches
Network Connectivity	Ethernet, USB
Supported Media Sizes	A4, A5, B5, Custom sizes
Supported Media Types	Plain paper, Heavy paper, Coated paper, Envelope
