4
4
4-161
4-161
Parts Replacement and Cleaning > Periodic Replacing Parts, Durable Parts, Cleaning Parts > Removing Primary Charging Wire (right) Pad Holder
Parts Replacement and Cleaning > Periodic Replacing Parts, Durable Parts, Cleaning Parts > Removing Primary Charging Wire (right) Pad Holder
Removing Primary Charging Wire (right) Pad Holder
<Preparation>
1) Open the Front Left Cover and the Front Right
Cover.
(Refer to page 4-54)
2) Remove Primary Charging Assembly.
(Refer to page 4-158)
1) Turn the gear by hand and move the cleaning pad arm to the center.
Gear
Cleaning pad arm
F-4-306
Caution : Be careful not to remove the shield plate (left) and the shield plate (right) of primary charging assembly at the same time.
Make sure to remove them one-by-one (because it may deform the primary charging assembly frame).
Shild plate (left) Shield plate (right)
F-4-307
