Technology > Pickup / Feed System > Pre-registration Area Control/Function
Technology > Pickup / Feed System > Pre-registration Area Control/Function
Pre-registration Area Control/Function
The paper fed from the pickup area, duplexing area or pickup option is fed to the active
registration area.
Pre-registration unit performs the pre-registration control, pre-registration roller disengage
control, skew detection and transparency detection.
PS42
PS36
PS34
PS26
PS41
PS91
PS90
PS27
PS115
PS117
PS116
PS119
PS120
SL3
M20 M18
M15
M16
M64
M54
M53
M63
M62
Paper dust cleaning brush
Paper dust cleaning brush
F-2-149
M15 POD deck feed motor
M16 Vertical path feed motor
M18 Pre-registration feed motor1
M20 Pre-registration feed motor2
M53 Duplexing feed motor5
M54 Duplexing feed motor6
M62 Deck feed motor1
M63 Deck feed motor2
M64 Deck feed motor3
SL3 Escape switch solenoid
PS26 POD deck path sensor
PS27 Vertical path sensor
PS34 Pre-registration roller1 disengage sensor
PS36 Pre-registration roller2 disengage sensor
PS41 Image standard sensor for transparency
PS42 Image standard sensor
PS90 Duplexing delivery sensor 7
PS91 Duplexing delivery sensor 8
PS115 Deck feed sensor 1
PS116 Deck feed sensor 2
PS117 Deck feed sensor 3
PS119 Double feed sensor (transmission)
PS120 Double feed sensor (reception)
