Canon imagePROGRAF IPF700 Service Manual

Chapter 6
6-23
T-6-8
T-6-9
T-6-10
T-6-11
6 LFSP_B OUT Feed motor drive signal B
J3001
Pin
Number
Signal name IN/OUT Function
1 VM OUT Power supply (+32V)
2- - -
3- - -
4 VM_CR IN Upper cover lock switch output signal
J3002
Pin
Number
Signal name IN/OUT Function
1 TH IN Thermister output signal
2 GND - GND
3 Vout IN Humidity sensor output signal
4 +5V OUT Power supply (+5V)
J3101
Pin
Number
Signal name IN/OUT Function
1 CRM_C OUT Carriage motor phase drive signal (C)
2 CRM_B OUT Carriage motor phase drive signal (B)
J3201
Pin
Number
Signal name IN/OUT Function
1 TANK_CLK OUT Ink tank clock signal
2 GND - GND
3 TANK_DAT2 IN/OUT Ink tank data signal 2
4 TANK_ON(+3.3V) OUT Power supply (+3.3V)
5 TANK_DAT1 IN/OUT Ink tank data signal 1
6 TANK_DAT0 IN/OUT Ink tank data signal 0
J2801
Pin
Number
Signal name IN/OUT Function

Canon imagePROGRAF IPF700 Specifications

General

Maximum Print Resolution	2400 x 1200 dpi
Ink Type	Pigment-based
Number of Ink Colors	5
Ink Colors	Cyan, Magenta, Yellow, Black, Matte Black
Connectivity	USB 2.0, Ethernet
Hard Drive	No
Operating Systems	Windows, Mac OS
Print Technology	Thermal Inkjet
Media Thickness	Up to 0.8 mm
Number of Nozzles	15, 360
Weight	103 lbs
