Chapter 7
7-7
(3) HEAD
Displays the following EEPROM information in the printhead.
T-7-2
(4) INK
Displays the numbers of days passed since installation of the following ink tanks.
If any ink tank that does not allow the printer to count the number of days passed is installed,an error message
is displayed.
T-7-3
(5) WARNING
Displays the warning history(up to 20 events). The newest event has the smallest history number.
(6) ERROR
Displays the error history(up to 20 events). The newest event has the smallest history number.
(7) INK CHECK
Displays the history of execution of "Ink Check Off" in the Main menu in the order of C,M,Y,MBK,MBK,and
BK from in this order.
0:No execution
1:Executed at least once
b. I/O DISPLAY(*To be supported by the next version)
Shows the statuses and sensors and switches on the display.
ON=1
TMP Ambient temperature C
SIZE LF Detected size of loaded media (feed direction)
0 is always detected for the roll media.
mm/inch
SIZE CR Detected size of loaded media (carriage direction) mm/inch
Displa
y
Description
S/N Serial number of printhead
LOT Lot number of printhead
Displa
y
Description Unit
BK Number of days passed since the BK ink tank was
installed
Day(s)
MBK Number of days passed since the MBK ink tank was
installed
Day(s)
MBK
2
Number of days passed since the MBK2 ink tank was
installed
Day(s)
C Number of days passed since the C ink tank was installed Day(s)
M Number of days passed since the M ink tank was
installed
Day(s)
Y Number of days passed since the Y ink tank was installed Day(s)
Display Description Unit
