3
Load the roll in the printer.
(See "Loading Rolls in the
Printer.")
→
P.539
Important
•
When printing without borders, definitely set the blue Switch on the platen to the ● side. If the switch is set incor-
rectly, print quality may deteriorate.
(See "Setting the Blue Switch on the Platen.")
→
P.974
Loading and Printing on Rolls
iPF8400
User's Guide
Basic Printing Workflow
Printing procedure
26
25
27
