Canon imagePROGRAF TM-240 Online Manual

Paper Source
Shows the source from which paper is supplied.
You may be able to switch the paper source with the printer driver.
Roll Paper
Feeds paper using roll paper.
Cut Sheet
Feeds paper using the cut sheet.
Important
• Depending on the media type and size, the Paper Source settings that can be selected may differ.
Roll Paper Width
Select the roll paper width.
Select the width that matches the width of the roll paper loaded in the printer.
If you select Custom Size (XXXX), the paper size set in the printer will be used.
The paper information set in the printer can be confirmed in Get Information... in the Main sheet.
If you select User-defined1 (XXXX) or User-defined2 (XXXX), the Custom Size Settings dialog box is
displayed, where you can specify the paper length and width.
Roll Paper Options...
Displays the Roll Paper Options dialog box.
You can specify auto cut, banner printing, and other settings for printing on roll paper.
Output Method...
Displays the Output Method dialog box.
You can select Output Method and specify save settings for saving documents to a box.
Note
• Depending on the model you are using, Output Method... may not be displayed.
Size Options...
Displays the Paper Size Options dialog box.
The Paper Size Options dialog box allows you to create and register any user-defined paper.
Custom Size Settings dialog box (Paper Size)
This dialog box allows you to specify the size (width and height) of the custom paper.
Paper Size
Specifies the Width and the Height of the custom paper. Measurement is shown according to the
units specified in Units.
Units
Select the unit for entering a user-defined paper size.
Borderless Setting dialog box
Adjust how much of the document extends off the paper during borderless printing, and configure the
three-sided borderless setting.
229

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
