Font
Selects the font for the stamp text string.
Style
Selects the font style for the stamp text string.
Size
Selects the font size for the stamp text string.
Color
Select the color of the stamp text string.
Delete
Deletes an unnecessary stamp.
Specify the title of an unnecessary stamp from the Stamps, and click this button.
Outline
Selects a frame that encloses the stamp text string.
Print Style
Select the stamp printing method.
Select Transparent to print the stamp on the back of the document, and select Overlap to print the
stamp on the front.
Position
Specifies the stamp position on the page.
You can specify values in X and Y to set the coordinates, or you can drag the horizontal and vertical
slide bars to the left/right or up/down to change the coordinates.
Move to Center
Moves the stamp to the center of the paper.
Angle
Set the stamp positioning angle.
You can specify a value in Set Angle to set the angle, or you can drag the slide bar left/right to
change the angle.
When specifying an angle value, set a value in the range of -180 to 180.
Stamp first page only
Select this check box if you want to print a stamp only on the first page.
Page Options dialog box
Specify the print settings, such as date, user name, and page number.
Print Date
Select the position for printing the date.
Print Time Also
Prints the time along with the date.
Print User Name
Select the position for printing the user name.
Print Page Number
Select the position for printing the page number.
236

Table of Contents

Other manuals for Canon imagePROGRAF TM-240

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF TM-240 and is the answer not in the manual?

Canon imagePROGRAF TM-240 Specifications

General IconGeneral
ColorYes
Printing colorsPigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Print head nozzles15360
Number of print cartridges5
Page description languagesCALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness0.07 - 0.8 mm
Print margin roll20 mm
Maximum print sizeA1 (594 x 841 mm)
Maximum roll width610 mm
Maximum roll length18 m
Maximum roll diameter150 mm
Paper tray media typesCut sheet, Roll
Print margin cut-sheet20, 31, 3 mm
Borderless printing media sizesA1, A2, A3, A3+, B2, B4
USB connectorUSB Type-B
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.1 W
Power consumption (sleep)2.2 W
Power consumption (typical)59 W
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Sustainability certificatesCE, UKCA
Control typeTouch
Product colorBlack, Grey
Display diagonal4.3 \
Sound pressure level (standby)35 dB
Sound pressure level (printing)39 dB
Mac operating systems supportedMac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supportedWindows 10, Windows 11, Windows 7, Windows 8.1
Weight and Dimensions IconWeight and Dimensions
Depth748 mm
Width978 mm
Height439 mm
