Canon imagePROGRAF TM-240 Online Manual

Note
• It will be displayed if you select Yes in Spooling at Printer Driver in the Special Settings dialog
box.
Format Settings
The Format Settings dialog box opens, and you can set the format.
Format Settings dialog box
Set the format to be used when printing the contents set in the Page Options dialog box.
Font
Select the font type.
Style
Select the font style.
Size
Select the font size.
Color
Select the font color.
Special Settings dialog box
The Special Settings dialog box allows you to change the print processing method if you do not get the
print results you want.
Settings Summary
This is a list of items that you can set in the Special Settings dialog box.
When you click an item that you want to set, the setting contents are displayed outside the box.
Spooling at Printer Driver
Set whether print jobs are to be spooled in the print driver or whether PageComposer processing
is to be performed.
Setting No (Use RAW Spooling) or Yes may improve the print results or the printing speed.
Also, depending on the setting, you may not be able to use some of the driver functions.
FineZoom Settings
Use this function to print on long paper.
Yes
The print problem may be corrected.
Select this in usual cases.
No
Image distortions may be corrected (for example, small lines may be eliminated).
Preview Switching
If you check the Preview before printing check box on the Main tab and then print,
PageComposer starts.
Application Color Matching Priority
You can assign higher priority to color management by the application software.
237

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
