• When selecting Barcodes in Manage remaining roll amount and if the barcode is printed.•
The type and amount of paper left is automatically detected based on the barcode printed on the
roll. There is no need to specify the type and length of the paper.
• When selecting Barcodes in Manage remaining roll amount and if the barcode is not•
printed.
◦ When selecting Manual in Media type selection method.◦
A menu for selection of the media type and length is shown on the touch screen.Operate the
touch screen, select the media type to be used, and enter its length.
◦
When selecting Auto with confirmation in Media type selection method.
◦
A menu for selecting the estimated media type candidates and the paper length. Interact with
the touch screen, select the media type you want to use, and enter the length.
◦
When selecting Auto detect in Media type selection method.
◦
A menu for selecting the estimated media type candidates and the paper length.After 5
seconds, the paper type of the first item is selected. If you choose a different candidate, you
can use the touch screen to select the type of paper you want.
Note
• If you have selected Auto with confirmation or Auto detect in the Media type selection•
method and you are using the barcode to manage the remaining roll paper, the barcode is read
first. If it fails to read the barcode, it will detect the media type from the estimated result and
display the candidate.
•
For details on media types that you can select, see "Paper Information List."
•
• If Media type selection method is set to Use current media type, you do not have to select a•
paper type.
• The width of the roll paper is automatically detected by the printer when the paper is loaded.•
When using roll paper with a user-defined size width, the detected width length and the set width
length must exactly match, so even if the correct roll paper is loaded, detection may fail.
In this case, you can improve it by setting the roll paper width you want to use in Add priority roll
paper width.
Add priority roll paper width
16.
Close the roll paper cover.
16.
262

Canon imagePROGRAF TM-240 Specifications

General

Color	Yes
Printing colors	Pigment black, Pigment cyan, Pigment magenta, Pigment matte black, Pigment yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Print head nozzles	15360
Number of print cartridges	5
Page description languages	CALS G4, HP-GL/2, HP-RTL, JPEG
Media thickness	0.07 - 0.8 mm
Print margin roll	20 mm
Maximum print size	A1 (594 x 841 mm)
Maximum roll width	610 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Cut sheet, Roll
Print margin cut-sheet	20, 31, 3 mm
Borderless printing media sizes	A1, A2, A3, A3+, B2, B4
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	59 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	CE, UKCA
Control type	Touch
Product color	Black, Grey
Display diagonal	4.3 \
Sound pressure level (standby)	35 dB
Sound pressure level (printing)	39 dB
Mac operating systems supported	Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8.1

Weight and Dimensions

Depth	748 mm
Width	978 mm
Height	439 mm
