Dimensions of Each Part

7-4

Appendix

Dimensions of Each Part

■ Printer

If "LGL" is indicated in the cassette, this length is 436mm.

If "LGL" is indicated in the cassette, this length is 185 mm.

344.5

245

125.3*

251376.3*

367

(mm)

Cassette

Cassette protective cover

Face-down delivery tray
