Right-Hand Side of the Booklet maker
Illustration
A
B
[3] Right-hand side of the Booklet maker
Component - function table
Right-hand side of the Booklet maker
Component Function
A The stitch-wire cabinet The stitch-wire cabinet holds the spool of stitch-wire.
B Trim Bin The trim bin collects the paper that is trimmed from the edge
of the book
Right-Hand Side of the Booklet maker
Chapter 2 - Introduction to the Booklet maker
13
