Clear paper from the trim stop
Introduction
Clear paper from the trim stop if the books are not trimmed square. If paper trimmings collect on
the trim stop, the books are not trimmed square.
Illustration
B
C
A
[58] Trim Stop Guard
A
Orange Plastic Hand Screw
B Locking Plate
C Trim Stop Guard
A
[59] Trim Stop
A
Trim Stop
Step Action Information
1 Remove the trim bin.
4
Clear paper from the trim stop
