The mains input panel of the optional Book Stacker
Illustration
A
B
C
D
E
[5] The mains input panel of the Book Stacker
Component - function table
The mains input panel of the Book Stacker
Component Function
A Rating and serial label The rating label displays the type of machine, serial
number, power use, and fuse information.
B Voltage advisory label The voltage advisory label shows that the input voltage
is 230 V AC. The 230 V power is supplied by the Océ
BLM550
+
.
C Power input connector The power input connector is used to connect the power
supply from the Océ BLM550
+
to the Book Stacker.
D Power ON/OFF switch The mains power ON/OFF switch turns the Book Stacker
ON or OFF.
E Fuses The fuses make sure the operator and the machine are
protected if there is an electrical problem or short circuit.
