The BASIC Window
Introduction
The BASIC window gives you access to frequently-changed machine settings.
Button overview
The BASIC Window Buttons
Button Information
PAPER SIZE
Measure the accurate size of the printed paper before you make a
book.
Touch PAPER SIZE to enter the paper size. When the machine is in
operation, you can adjust the PAPER SIZE by a maximum of +/- 1
mm.
- PAGE DIRECTION
Touch PAGE DIRECTION to change the direction of the paper to
Landscape or Portrait.
- ROTATE
Touch ROTATE to set the sheet rotation ON or OFF. If you select
A4 portrait (USA: 8.5x11), ROTATE is set to ON automatically.
- PRESETS
Touch PRESET to select a standard paper size.
SET THICKNESS Use the SET THICKNESS window to define the thickness of the
set.
Measure the thickness of the set before you make a book. Touch
SET THICKNESS and enter the value.
Or
Use AUTO and SHEET THICKNESS to automatically calculate the
SET THICKNESS.
- AUTO
Touch SET THICKNESS > AUTO to select automatic adjustment of
SET THICKNESS. Enter the SHEET THICKNESS.
The sheets are counted when they enter the machine. The SET
THICKNESS is calculated from the SHEET THICKNESS and the
sheet count.
- SHEET THICKNESS
Use SHEET THICKNESS to enter the measured thickness of one
sheet of paper.
SHEET THICKNESS determines the maximum number of sheets
that is allowed. The maximum number is displayed on the screen.
STITCHES Touch STITCHES to select the number of stitches. Available op-
tions are 1 - 6. The machine automatically calculates the position
of the stitches according to the size of the paper. Select 0 to turn
off the stitch function.
-STITCH PITCH The stitch pitch is the space between the stitches. The machine au-
tomatically calculates the stitch pitch according to the size of the
paper.
If a non-standard stitch pitch is needed, use STITCH PITCH to
make the adjustment.
- AUTO
Touch AUTO to select the default stitch pitch.
4
The BASIC Window
Chapter 4 - The User Interface
33
