The MENU Window
Introduction
MENU shows the settings that are not changed during day-to-day operation.
These settings include
• Change the Access Level
• Change the display language
• Advanced machine settings that are accessed by a person who has the correct access-code.
Button overview
The MENU Window Buttons
Button Information
ACCESS LEVEL
The Touch Screen has five different access levels
• Operator
• Supervisor
• Service
• Distributor
• Factory
Touch ACCESS LEVEL and select the correct level from the list.
The last three levels are protected by access codes. To protect the
job settings, the supervisor level allows jobs to be locked.
CURRENT LANGUAGE
Touch one of the flags to select the language you need.
AXES Touch AXES to re-reference individual axes. Supervisor access
level is needed for this function.
Other functions on this button are used by the service engineer.
BRIDGE Touch BRIDGE to re-reference the bridge axes. Supervisor access
level is needed for this function.
Other functions on this button are used by the service engineer.
SERVICE OPTIONS
This button is used by the service engineer.
TEST
This button is used by the service engineer.
COUNTERS
The counters display the
• number of books that have been made
• number of sheets that have been processed
• number of stitches that have been used
-RESET
Touch RESET to reset the book, sheet and stitch counter. Use RE‐
SET after operator maintenance to the stitch head.
Touch and hold RESET. A red line appears. The red line fills from
left to right. Hold RESET until the red line reaches the right-hand
side.
The MENU Window
Chapter 4 - The User Interface
39
