3. Lift the clincher frame to the vertical position.
Lower the Clincher Frame
1. Lower the clincher frame.
2. Turn the locking handle to the right , until the handle is tight.
3. Check that the locking handle will not be hit by the folder cover when you close the folder
cover. The locking handle should point towards the middle of the machine. If necessary, lift
and rotate the locking handle to a new position.
Lift and Lower the Clincher Frame
Chapter 5 - Standard Tasks
47
