Carestream CS 8100 3D - Mobile Components

4 Chapter 2 CS 8100 3D Overview
Mobile Components
Figure 1 illustrates the:
• Up and down movement of the unit
• Rotation and translation movement of the rotative arm
Figure 1 CS 8100 3D Unit Mobile Components
Important: The patient can enter by either the left side or the
right side of the unit.
