84 Chapter 7 3D Object Acquisition
Launching the X-Ray To Acquire an Image of the NobelGuide™ or
NobelClinician™ Calibration Phantom
To launch the X-ray, follow these steps:
1. Leave the X-ray room and close the door.
2. On the Acquisition interface, when is green, press and hold the exposure button of the X-ray
remote control until the end of acquisition.
The indicator in the acquisition interface turns yellow and a warning sound is emitted to
indicate that X-ray emission is in progress.
The acquired image appears in the Preview Screen.
3. The animated display in the Acquisition interface changes to demonstrate how to correctly
position the next item to be scanned. Repeat steps 1 to 2.
4. Once all items have been scanned, wait for the 3D object reconstruction.
The reconstruction object will display in the image browser.
Important: If you have a problem that requires you to stop the
acquisition, release the exposure button of the remote control or
press the red emergency stop button.
