Panoramic and 3D Modality User guide for CS 8100 3D Family (SM842) Ed07 81
appears in the Acquisition Export Mode field.
7. Select either one of the appliance acquisition options.
Launching the X-ray
To launch the X-ray, follow these steps:
1. Leave the X-ray room and close the door.
2. On the Acquisition interface, when is green, press and hold the exposure button of the X-ray
remote control until the end of acquisition.
The indicator in the acquisition interface turns yellow and a warning sound is emitted to
indicate that X-ray emission is in progress.
The acquired image appears in the Preview Screen.
3. Once all items have been scanned, the Acquisition interface closes. Wait for the 3D object
reconstruction.
The reconstruction object will display in the image browser.
Important: The animated display screen will guide you on how to
position the acquisition mode that you have selected.
Important: If you have a problem that requires you to stop the
acquisition, release the exposure button of the remote control or
press the red emergency stop button.
