Carestream CS 8100 3D - General Functional Components

Panoramic and 3D Modality User guide for CS 8100 3D Family (SM842) Ed07 5
General Functional Components
The following figures illustrate the general functional components of the unit.
Figure 2 Unit Functional Components
1 ON/OFF button 7 Temp le su pport
2 Emergency stop knob 8 Digital sensor
3 Unit rotative arm 9 Unit head
4 X-ray source assembly 10 X-ray remote control
5 Unit column 11 Computer hosting the imaging and the acquisition
software
6 Head and chin rest
10
11
2
6
4
3
1
8
5
9
7
