36 Chapter 5 Acquiring Panoramic Images
3. Click . The selected are of interest will highlight:
4. Double click . appears for a TMJ x4 acquisition.
5. (Optional) If the default parameter setting is not adapted to your patient type, click the Parameter
button:
• Select the appropriate parameters.
• Click and select Memorize Anatomy setting to save the new parameter settings as
future default settings.
6. On the head and chin rest, remove or , place and cover it with a hygienic
barrier.
Preparing and Positioning the Adult and Pediatric Patient
To prepare and position the patient, follow these steps:
1. Ask the patient to remove all metal objects.
2. Ask the patient to wear a lead apron. Ensure that the apron lays flat across the patient’s shoulders.
