68 Chapter 7 3D Object Acquisition
Launching the Plaster Acquisition
To launch the acquisition, follow these steps:
1. Select either the lower jaw or upper jaw acquisition mode.
2. Follow the on-screen animated instruction on how to correctly position the upper jaw or lower jaw
plaster at the center of the black foam.
3. Leave the X-ray room and close the door.
4. On the Acquisition interface, when is green, press and hold the exposure button of the X-ray
remote control until the end of acquisition.
The indicator in the acquisition interface turns yellow and a warning sound is emitted to
indicate that X-ray emission is in progress.
The acquired image appears in the Preview Screen.
5. Once all items have been scanned, the Acquisition interface closes. Wait for the 3D object
reconstruction.
The reconstruction object will display in the image browser.
Important: The animated display screen will guide you on how to
position the acquisition material that you have selected.
Important: If you have a problem that requires you to stop the
acquisition, release the exposure button of the remote control or
press the red emergency stop button.
