SECTION 25 - FRONT AXLES 19
Assemble the bearing cone (8) on the swivel hous-
ing (10).
Assemble the wheel hub (7) on the swivel housing
(10) and insert the bearing cone (5).
Assemble the thrust washer (4). Screw the screws
(3).
Assemble a new O-ring (6). Assemble the cover (2)
and screw two screws (1). Tighten the screws (1) to
the specified torque.
F27377
8 5
7
10
1
2
6
F27366
