32 SECTION 25 - FRONT AXLES
Loosen the bolt (4).
Take the rear support (5) out from the differential
support.
Remove the O-ring (6) from the bush (8) in rear sup-
port (5).
NOTE: this is a destructive operation for the O-ring.
Remove the bolt (4).
Remove the bush (8) from the rear support (5).
Remove the bushes (6) from the rear support (5).
F27214
4
5
F27215
5
7
F27216
5
8
4
F27217
6
5
