SECTION 25 - FRONT AXLES 33
Remove the cover (11) from differential support with
a lever.
Remove the O-ring (12) and the seal ring (13) from
the cover (11).
NOTE: destructive operation for the seal rings.
Remove the bush (9) and the thrust washer (10)
from differential support only if necessary.
NOTE: it is advisable to heat the bush (9) to make
easy this operation; this is a destructive operation
for the bush.
Loosen the bolt (19).
Take the front support (20) out from the axle hous-
ing (15).
F27218
11
F27219
11
12
13
F27220
9
10
F27221
15
20
19
