SECTION 25 - FRONT AXLES 35
Assemble the cover (11) to the differential support.
Apply sealant on the bushes (6) contact surface.
Assemble the bushes (6) to the rear support (5) with
a pad and a hammer.
Assemble the bush (8) in the rear support (5).
SWARNING
Align the bush hole with the bolt (4) hole.
Mount the bolt (4).
Lubricate with grease a new O-ring (7).
Insert the O-ring (7) in the rear support (5).
F27218
11
F27217
6
5
F27216
5
8
4
F27215
5
7
