SECTION 25 - FRONT AXLES 107
DIFFERENTIAL SUPPORT GROUP
Disassembly
Drain the oil completely from the differential.
Loosen and remove the screws (2) of the differential
support (1).
Remove the differential support (1) from the axle
housing (14).
SWARNING
Support the differential support with a rope or other
appropriate means.
F27411
4
5
3
1
2
7
89
6
13
14
12
11
10
9
8
F27501
14
1
2
