108 SECTION 25 - FRONT AXLES
Loosen and remove the screws (9) to take out the
two ring nut retainers (8).
Before removing the bolts, mark both half-collars
(11) and the differential support with permanent ref-
erence marks to avoid inverting them during re-as-
sembly. Mark the area between the ring nuts (3) and
(7) and the differential support (1) as well.
Unscrew the adjuster ring nuts (3) and (7) using tool
380000406 and a wrench.
Remove the 4 screws (12) and remove both half-
collars (11).
NOTE: check that the bushes (10) remains in their
housings.
F27395
9
8
9
8
11
3
1
F27422
F27423
3
F27424
12
11
10
