14 SECTION 27 - REAR AXLE
Remove the snap ring (14) from the axle inner cen-
tral body.
Using an rubber hammer, take out the pinion (12).
Remove from the pinion (12), the spacer (7) and by
means of extractors, the bearings (11) and (13).
12
14
F29553
