SECTION 27 - REAR AXLE 53
Remove the O-ring (4) and (19) from its housing and
from oil pipe hole and check its conditions.
Collect the brake flange (7) and place it on a work-
bench or fix it in a clamp.
Unscrew screws (11).
Take from the piston (14), the springs (13) and the
bushes (12) and (27) and spacer (26).
Unscrew the breather (21) from the brake flange (7).
F28037
4
19
F27313
11
7
F28038
26
27
14
13
12
F28039
21
7
