Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.9
PPP Username and Password
PPP requires that you have a user name and password to establish your connection. In the boxes
below, enter the user name and password that your ISP has provided to you.
PPP Configuration Options
Option
Example
Meaning
PPP Username
Case
Enter the username provided by your ISP
PPP Password
Ca43XTZ
Enter the Password provided by your ISP
Authentication method
Auto
Select form the drop down menu
 Auto
 PAP
 CHAP
 MS Chap
Enable full cone Nat (by default not enabled)
Dial on demand (with idle timeout timer)
Note this option only appears if ‘dial on demand is selected. Inactivity Timeout in
minutes [1-4320) (default is 0)
PPP IP Extension (not enabled by default)
Use Static IP Address
NB. option below only appears if Static IP Address is selected.
IPv4 Address (enter your static IP Address if option selected)
Example 172.16.40.23
Enable PPP Debug Mode (not selected by default)
Multicast Proxy
Enable IGMP Multicast Proxy (not selected by default)
Having selected your options select ‘ Next’ and the following page appears.
Routing -- Default Gateway
The Default Interface list can have multiple WAN Interfaces served as system default gateways but
only one will be used according to the priority with the first being the highest, and the last one the
lowest priority if the WAN is connected. The priority order can be changed by removing and re-
adding the interfaces.
Select Default Gateway Interfaces
Available Routed WAN Interfaces
pppoA


Note if only one interface has been configured
it will be automatically added to the default
gateway
Select Next to proceed to the DNS Server configuration
