OPERATION & MAINTENANCE MANUAL STE35SR
If the tension is low, rubber pad shoe will fall off
in the following conditions:
1. When skipping over the edge of the road,
stones or a larger gap (about more than 20cm
(8in)) should not steer. When crossing the
obstacles, walk at right angles to the obstacles.
2. When reverse the slope, do not turn in the
course of moving from the ground. If you must
turn on the slope, be sure to move slowly.
3. To avoid walking along the edge of the slope or
on uneven ground, resulting in one side of the
track lifted (machine inclination of more than 10
degrees), the other side of the track on the
ground. In order to avoid damaging to rubber
pad shoe and road liner, walking on both sides
of tracks on the ground.
4. If according to the above 1~3 operate the
machine, rubber pad shoe will become loose.
Don't let the machine turn in the position shown
in the picture.
