Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Chapter 4 Removal and Replacement Procedures
Removing and Installing the AC-Input Power Supplies
Removing and Installing the AC-Input Power Supplies
This section describes how to remove and install AC power supplies in the Catalyst 6500 series chassis.
The AC-input power supplies have three different form factors, which are not interchangeable between
the Catalyst 6500 series chassis. Table 4-1 lists the AC-input power supplies, the chassis that they are
supported on, and the corresponding removal and replacement procedures.
Removing and Installing the 950 W and 1400 W AC-Input Power Supplies
This section describes how to remove and install the 950 W and 1400 W AC-input power supplies for
the Catalyst 6503 and the Catalyst 6503-E switches. The section is divided into the following topics:
• Required Tools, page 4-2
• Removing a 950 W or 1400 W AC-Input Power Supply, page 4-3
• Installing a 950 W or 1400 W AC-Input Power Supply, page 4-5
Note The 950 W and 1400 W AC-input power supplies can be installed in the Catalyst 6503 and the
Catalyst 6503-E switch chassis only.
Required Tools
You might need a flat-blade or number 2 Phillips-head screwdriver to loosen or tighten the captive
installation screws on the power supply.
Table 4-1 Catalyst 6500 Series AC-Input Power Supplies Removal and Installation Procedures
Power Supply Chassis Supported Removal and Installation Procedure
950 W, 1400 W Catalyst 6503, Catalyst 6503-E “Removing and Installing the 950 W
and 1400 W AC-Input Power
Supplies” section on page 4-2
2700 W Catalyst 6504-E “Removing and Installing the
2700 W AC-Input Power Supply”
section on page 4-6
1000 W, 1300 W,
2500 W, 3000 W,
4000 W, and 6000 W
Catalyst 6506, Catalyst 6506-E,
Catalyst 6509, Catalyst 6509-E,
Catalyst 6509-NEB,
Catalyst 6509-NEB-A,
Catalyst 6513
“Removing and Installing the
1000 W, 1300 W, 2500 W, 3000 W,
4000 W, and 6000 W AC-Input
Power Supplies” section on
page 4-9
