Cisco 6509 - Catalyst Chassis Switch User Manual

C-1
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
APPENDIX
C
Repacking the Switch
If you need to return or move the Catalyst 6500 series switch chassis, follow these steps to repack the
switch using the original packaging material:
Step 1 Set the chassis in the bottom pallet. (See Figure C-1.)
Step 2 Place the packing bag over the chassis.
Step 3 Place the front-packing material and power supply packing material around the chassis.
Step 4 Place the power supplies in the spaces provided in the power supply packing material. (See Figure C-1.)
Step 5 Place the top-packing material over the top of the chassis and power supplies.
Step 6 Place the rack-mount kit and the accessory kit on the top-packing material.
Note You must include the accessory kit for the final packaging to fit properly.
Step 7 Place the outside carton over the entire package.
Step 8 Fold the outside carton down over the top and seal with packing tape.
Step 9 Wrap three packing straps tightly around the top and bottom of the package to hold the outside carton
and the bottom pallet together. (See Figure C-2.)
