A-20
Catalyst 6500 Series Switches Installation Guide
OL-5781-04
Appendix A Power Supply Specifications
1400 W AC-Input Power Supply
1400 W Power Supply AC Power Cords
Table A-10 lists the specifications for the AC power cords that are available for the 1400 W AC-input
power supply. These power cords plug into the 1400 W PEM (PEM-20A-AC+); not directly into the
power supply. The table includes references to power cord illustrations.
Note All 1400 W power supply power cords are 14 feet (4.3 meters) in length.
Note All 1400 W power supply power cords have an IEC60320/C19 appliance plug at one end.
Output holdup time 20 ms minimum
Heat Dissipation 1193 BTU/hour (approx.)
Front panel LEDs
• INPUT OK • Green—Source AC voltage is OK. (Input voltage
is 85 VAC or greater.)
• Off—Source AC voltage falls below 70 VAC, is
not present, or the power supply is turned off.
• FAN OK • Green—Power supply fan is operating properly.
• Off—Power supply fan failure is detected.
• OUTPUT FAIL • Red—Problem with one or more of the DC-output
voltages of the power supply is detected.
• DC-output voltages within acceptable margins.
Weight 7.8 lb (3.5 kg)
Table A-9 1400 W Power Supply Specifications (continued)
Specification Description
Table A-10 1400 W Power Supply AC Power Cords
Locale
Power Cord
Part Number Source Plug Type Cordset Rating
Power Cord
Reference
Illustration
Argentina CAB-7513ACR= IRAM 2073 10 A, 250 VAC Figure A-28
Australia, New Zealand CAB-7513ACA= SAA AS 3112 15 A, 250 VAC Figure A-29
People’s Republic of
China
CAB-AC16A-CH= GB16C 16 A, 250 VAC Figure A-34
Continental Europe CAB-7513ACE=
CAB-AC-2500W-EU=
CEE 7/7
CEE 7/7
16 A, 250 VAC
16 A, 250 VAC
Figure A-30
Figure A-38
